Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Extended
# Name Access Type
Default
a
a. If an attribute is not implemented, the module will use this value instead
Comment
2 Enable HICP Get BOOL True Value:Meaning:
True HICP enabled
False HICP disabled
(see “Secure HICP (Secure Host IP Configu-
ration Protocol)” on page 192)
3 Enable Web Server Get BOOL True Value:Meaning:
True web server enabled
False web server disabled
(see “Web Server” on page 24)
5 Enable Web ADI access Get BOOL True Value:Meaning:
True web ADI access enabled
False web ADI access disabled
(see “Web Server” on page 24)
6 Enable FTP server Get BOOL True Value:Meaning:
True FTP server enabled
False FTP server disabled
(see “FTP Server” on page 22)
7 Enable admin mode Get BOOL False Value:Meaning:
True FTP Admin mode enabled
False FTP Admin mode disabled
(see “FTP Server” on page 22)
8 Network Status Set UINT16 - See “Network Status” on page 173
9 Port 1 MAC address Get Array of UINT8 - MAC address for Ethernet port 1, 6 bytes
10 Port 2 MAC address Get Array of UINT8 - MAC address for Ethernet port 2, 6 bytes
11
b
b. If ACD functionality is disabled using this attribute, the ACD attributes in the CIP TCP/IP object (F5h) are not avail-
able.
Enable ACD Get BOOL True Value:Meaning:
True ACD enabled
False ACD disabled
12 Port 1 State Get ENUM Enable State of Ethernet port 1, see “Port State” on
page 173
13 Port 2 State Get ENUM Enable State of Ethernet port 2, see “Port State” on
page 173
14 Reserved
15 Enable reset from HICP Get BOOL False Value:Meaning:
True Possible to reset the module from
HICP
False Not possible to reset the module from
HICP
16 IP configuration Set Struct of:
UINT32
(IP address)
UINT32
(Subnet mask)
UINIT32
(Gateway)
N/A The Anybus CompactCom writes the IP con-
figuration (IP address, Subnet mask, Gateway)
to this attribute whenever the configuration is
assigned or changed.
17 IP address byte 0 - 2 Get Array of
UINT8[3]
[0] : 192
[1] : 168
[2] : 0
This attributes holds the first three bytes of the
IP address. The attribute is used in Shift Reg-
ister Mode if the configuration switch value is
set to 1 - 245. The first three bytes of the IP
address will be given by the values in the
attribute and the last byte will be given by the
configuration switch value.
