Anybus CompactCom 40 EtherNet/IP User Manual

CIP Objects 88
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Instance Attributes
Extended
# Name Access Type Value Comments
1 Status Get DWORD - Bit #:
0-3:
4:
5:
6:
7
8 - 31:
Meaning:
When set to h, attribute #5 contains valid
configuration from DHCP or non-volatile
storage. When set to 2h, attribute #5 con-
tains valid configuration from hardware
settings. Remaining values are reserved
for future use.
Multicast pending if set to 1.
Interface configuration pending if set to 1.
A new configuration will be loaded at the
next reset.
AcdStatus. Set to 1 if an address conflict is
detected. Address conflict detection is
enabled/disabled in attribute #10.
AcdFault
(reserved, set to 0)
2 Configuration
Capability
Get DWORD 0000 0084h
- or -
0000 0094h
- or -
0000 00A4h
- or -
0000 00B4h
Bit #:
0-3:
4:
5:
6:
7:
8 - 31:
Meaning:
Always 4. For more information, consult
the CIP specifications.
The ‘Configuration Settable’-bit reflects the
value of instance attribute #9 in the “Ether-
Net/IP Host Object (F8h)” on page 161.
The module is hardware configurable
when this bit is set to 1. The bit will be set if
any of the address attributes is set in the
Network Configuration Object (04h) during
setup or if attribute #6 (Hardware configu-
rable address) in the Application Object
(FFh) is set.
Always 0. For more information, consult
the CIP specifications.
Always 1, the device is capable of detect-
ing address conflicts.
(reserved, set to 0)
3 Configuration
Control
a
Get/Set
a
DWORD - Value:
0:
2:
Meaning:
Configuration from non-volatile memory
Configuration from DHCP
4 Physical Link
Object
Get Struct of:
UINT (Path size)
Padded EPATH
-
0002h
20 F6 24 03h
-
-
Path to Ethernet Link Object, Instance #3
5 Interface
Configuration
a
Get/Set
a
Struct of:
UDINT (IP)
UDINT (Mask)
UDINT (GW)
UDINT (DNS1)
UDINT (DNS2)
STRING (Domain)
-
IP address
Subnet mask
Default gateway
Primary DNS
Secondary DNS
Default domain
6 Host Name Get/Set STRING - Host name of Anybus module
8 TTL Value Get/Set USINT 1 TTL value for EtherNet/IP multicast packets
