CIP Objects 91
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Instance Attributes
Extended
# Access Name Type Value Comments
1 Get Interface Speed UDINT 10 or 100 Actual Ethernet interface speed.
2 Get Interface Flags DWORD - See “Interface Flags” on page 92.
3 Get Physical Address Array of 6 USINTs (MAC ID) Physical network address, i.e. assigned MAC
address.
4 Get Interface Counters Struct of:
In Octets UDINT N/A Octets received on the interface
In Ucast Packets UDINT N/A Unicast packets received on the interface
In NUcast Packets UDINT N/A Nonunicast packets received on the interface
In Discards UDINT N/A Inbound packets with unknown protocol
In Errors UDINT N/A Inbound packets that contain errors (does not
include In discards)
In Unknown Protos UDINT N/A Inbound packets with unknown protocol
Out Octets UDINT N/A Octets sent on the interface
Out Ucast Packets UDINT N/A Unicast packets sent on the interface
Out NUcast Packets UDINT N/A Nonunicast packets sent on the interface
Out Discards UDINT N/A Outbound packets with unknown protocol
Out Errors UDINT N/A Outbound packets that contain errors (does
not include Out discards)
5 Get Media Counters Struct of: Media specific counters
Alignment Errors UDINT N/A Frames received that are not an integral num-
ber of octets in length
FCS Errors UDINT N/A Frames received that do not pass the FCS
check
Single Collisions UDINT N/A Successfully transmitted frames that have
experienced exactly one collision
Multiple Collisions UDINT N/A Successfully transmitted frames that have
experienced more than one collision
SQE Test Errors UDINT 0 The number of times the SQE test error mes-
sage is generated
(Counter not provided with current PHY inter-
face)
Deferred
Transmissions
UDINT N/A Frames for which the first transmission attempt
is delayed because the medium is busy
Late Collisions UDINT N/A The number of times a collision is detected
later than 512 bit-times into the transmission of
a packet
Excessive Collisions UDINT N/A Frames for which a transmission fails due to
excessive collisions
MAC Transmit
Errors
UDINT N/A Frames for which a transmission fails due to
an internal MAC sublayer receive error
Carrier Sense
Errors
UDINT N/A The number of times that the carrier sense
condition was lost or never asserted when
attempting to transmit a frame
Frame Too Long UDINT N/A Frames received that exceed the maximum
permitted frame size
MAC Receive Errors UDINT N/A Frames for which reception on an interface
fails due to an internal MAC sublayer receive
error
