Instance Attributes (Instance #20, QuickConnect)
This instance enables or disables the QuickConnect functionality from the application. Changes are valid
after reset or power cycle. The value of the QuickConnect attribute (#12) in the TCP/IP Interface ob-
ject (F5h), will change immediately.
QuickConnect has to be enabled in the Ethernet Host object (F9h) for this instance to be available.
See also ...
• “TCP/IP Interface Object (F5h)” on page 87
• “Ethernet Host Object (F9h)” on page 171
Extended
Multilingual Strings
The instance names and enumeration strings in this object are multi-lingual, and are translated based on
the current language settings as follows:
# Name Access Type Description
1 Name Get Array of CHAR ‘QuickConnect’
2 Data type Get UINT8 08h (= ENUM)
3 Number of elements Get UINT8 01h
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set ENUM Value Meaning:
00h Disable (default)
01h Enable
6 Configured Value Get ENUM Holds the configured value, which will be written to attribute
#5.
Value Meaning:
00h Disable (default)
01h Enable
Instance English German Spanish Italian French
3 IP address IP-Adresse Dirección IP Indirizzo IP Adresse IP
4 Subnet mask Subnetzmaske Masac. subred Sottorete Sous-réseau
5 Gateway Gateway Pasarela Gateway Passerelle
6 DHCP DHCP DHCP DHCP DHCP
Enable Einschalten Activado Abilitato Activé
Disable Ausschalten Desactivado Disabilitato Désactivé
7 Comm 1 Komm 1 Comu 1 Connessione 1 Comm 1
Auto Auto Auto Auto Auto
10 HDX 10 HDX 10 HDX 10 HDX 10 HDX
10 FDX 10 FDX 10 FDX 10 FDX 10 FDX
100 HDX 100 HDX 100 HDX 100 HDX 100 HDX
100 FDX 100FDX 100 FDX 100 FDX 100 FDX
