Anybus CompactCom 40 EtherNet/IP User Manual

CIP Objects 69
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Instance 07h Attributes (Heartbeat, Listen-Only Extended)
Extended
This instance is used as heartbeat for listen-only extended connections, and does not carry any attributes.
The state of connections made to this instance does not affect the state of the Anybus CompactCom 40
module, i.e. if the connection times out, the module does not switch to the Error state. The data size of
the Heartbeat instance in the Forward_Open-request should be 0 bytes, however other values are also
permitted.
The instance number for this instance can be changed by implementing the corresponding attribute in
the EtherNet/IP Host Object.
Instance 64h Attributes (Producing Instance)
Extended
The instance number for this instance can be changed by implementing the corresponding attribute in
the EtherNet/IP Host Object.
See also...
• “Network Data Exchange” on page 19
• “EtherNet/IP Host Object (F8h)” on page 161 (Instance attribute #7)
Instance 96h Attributes (Consuming Instance)
Extended
The instance number for this instance can be changed by implementing the corresponding attribute in
the EtherNet/IP Host Object.
See also...
• “Network Data Exchange” on page 19
• “EtherNet/IP Host Object (F8h)” on page 161 (Instance attribute #8)
# Name Access Type Value
3 Data Set N/A - (The data size of this attribute is zero)
4 Size Get UINT 0 (Number of bytes in attribute 3)
# Name Access Type Value
3 Produced Data Get Array of BYTE This data corresponds to the Write Process Data.
4 Size Get UINT Number of bytes in attribute 3
# Name Access Type Value
3 Consumed Data Set Array of BYTE This data corresponds to the Read Process Data.
4 Size Get UINT Number of bytes in attribute 3
