Anybus CompactCom 40 EtherNet/IP User Manual

175
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Object Attributes (Instance #0)
Instance Attributes
Extended
# Name Access Data Type Value
1 Name Get Array of CHAR ‘Application File System Interface’
2 Revision Get UINT8 01h
3 Number of instances Get UINT16 -
4 Highest instance no. Get UINT16 -
11 Max. no. of instances Get UINT16 Max number of instances supported by the application.
13 Total disc size Get Array of UINT32 -
14 Free space Get Array of UINT32 -
# Name Access Type Description
1 Instance type Get UINT8 Value:Type:
00h Reserved
01h File instance
02h Directory instance
2 File size Get UINT32 File size in bytes (zero for directories)
3 Path Get Array of CHAR Path where instance operates
