Anybus CompactCom 40 EtherNet/IP User Manual

CIP Objects 64
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Class Attributes
Instance Attributes
Extended
# Name Access Type Value
1 Revision Get UINT 0001h (Object revision)
2 Max instance Get UINT Maximum instance number
3 Number of
instances
Get UINT Number of instances
100 Module ID List Get Array of UINT32 If modular device functionality is enabled, a request to this attribute
will generate a Get_List request to the Modular Device Object in
the host application.
# Name Access Type Value
1 Vendor ID Get UINT
005Ah (HMS Industrial Networks AB)
a
a. Can be customized by implementing the EtherNet/IP Host Object, see “EtherNet/IP Host Object (F8h)” on page
161
2 Device Type Get UINT
002Bh (Generic Device)
a
3 Product Code Get UINT
0037h (Anybus CompactCom 40 EtherNet/IP)
a
4 Revision Get Struct of:
USINT
USINT
Major and minor firmware revision
a
5 Status Get WORD See “Device Status” on page 65
6 Serial Number Get UDINT
Unique serial number (assigned by HMS)
a
7 Product Name Get SHORT_STRING
“Anybus CompactCom 40 EtherNet/IP (TM)”
a
11 Active language Set Struct of:
USINT
USINT
USINT
Requests sent to this instance are forwarded to the Application
Object. If the request is accepted, the module will update the lan-
guage accordingly.
12 Supported Lan-
guage List
Get Array of: List of languages supported by the host application. The list is read
from the Application Object and translated to CIP standard. By
default the only supported language is English. The application has
to implement the corresponding attributes in the application object to
enable more languages.
Struct of:
USINT
USINT
USINT
