Connection Description
A Power cables
Supply power to the computer and the QuantStudio
™
6 and 7
Flex Systems.
[1]
B
LAN connection or
Ethernet cable
[2]
Connects the QuantStudio
™
6 and 7 Flex Systems (Ethernet
port) to the Ethernet port on the network interface card in the
computer. The components can be connected over a local area
network or a via a direct physical connection.
C DVI cable Connects the monitor to the computer (DVI port).
D
Barcode scanner
cable
Connects the optional barcode scanner to the computer (USB
port).
E Keyboard cable Connects the keyboard to the computer (USB port).
F Mouse cable Connects the mouse to the computer (USB port).
[1]
S
upplies 115/230 V depending on the geographic location of the installation.
[2]
Supplied with the QuantStudio
™
6 and 7 Flex Systems.
Appendix H Ins
trument specification and layout
QuantStudio
™
6 and 7 Flex Systems layout and connections
H
168
QuantStudio
™
6 and 7 Flex Real-Time PCR Systems v1.6 Maintenance and Administration Guide
