APT 300XAC Series User Manual

154
Part Number
Qty.
Ref.
Designator
Description
39664
2
-
Front Wheel with brake 3.5”
(360XAC)
39665
2
-
Rear Wheel 3.5” (360XAC)
38916
1
-
Graphic LCD Display
38021
2
-
Diode LED Red Square
39168
1
-
Output Terminal Block 75A, 3
positions (340XAC, 360XAC)
39169
1
-
Sense Terminal Block 20A, 2
positions (340XAC, 360XAC)
39170
1
-
Input Terminal Block 30A, 3
positions (340XAC, 360XAC)
39171
1
-
Input Terminal Block 30A, 4
positions (360XAC)
39189
1
CN1
Output Terminal Block 30A, 5
positions. Part mounted on the PCB
OPT61000 (310XAC, 320XAC)
39209
1
CN3
Input Terminal Block 30A, 3
positions. Part mounted on the PCB
PFC61000 (310XAC, 320XAC)
PCB Assemblies
38967
1
KEY6700
Keypad Board
39063
1
USB/RS232
USB/RS232 Interface Board
38779
1
REM6700
Remote Input Board
38305
1
CGP-03
GPIB Interface Board
38819
1
38818
Ethernet Card
39119
1
CON61000
Main Control Board
39120
1
ANG66000
Analog Board
39121
1
AMP61000
Amplifier Board (310XAC)
39122
1-(320XAC)
2-(340XAC)
3-(360XAC)
AMP61000
Amplifier Board (320XAC, 340XAC,
360XAC)
39123
1
DDC61000
DC to DC Converter Board
(310XAC)
39124
1-(320XAC)
2-(340XAC)
3-(360XAC)
DDC61000
DC to DC Converter Board
(320XAC, 340XAC, 360XAC)
39125
1
PFC61000
PF Correct Board (310XAC)
39126
1
PFC61000
PF Correct Board (320XAC)
39127
1
PFC61000
PF Correct Board (340XAC)
