APT 300XAC Series User Manual

34
12. External Sense Output Terminal Block: provides screw terminals for
external voltage sense leads.
12a. L: Line voltage sense screw terminal.
12b. N: Neutral voltage sense screw terminal.
3.2.3 Soft Keys
The soft keys enable the operator to navigate through the instrument, change the
meter display, name files, and change parameters. Below is a list of all available
soft keys.
Soft Key
Description
Memory
Allows you to enter the memory location to change a
memory
Step
Allows you to change step location
Edit
Allows you to edit parameters
<more>
Allows you to move to additional selections
Result
Allows you to review the results after a test
System
Allows you to change the instruments settings and
parameters
Exit
Allow you to exit the current screen
Name
Allow you to name a memory
List
Allows you to see the list of memories available

Allows you to scroll through the list sequentially, or
move down a character listing
Page ^
Allows you to page up through the list
Page 
Allows you to page down through the list
Load
Allows you to load a memory
Enter
Allows you to enter a parameter
Esc
Allows you to exit a parameter setting screen
<top>
Allows you to move to the previous screen of
selections
>
Allows you to move to the right through a character
listing
<
Allows you to move to the left through a character
listing
Select
Allows you to select a memory
Meter
Allows you to toggle through the different meter
settings/readings
