5. Test Modes
5.1 Description of Test Modes
Within the System Parameter settings of Auto Mode you have two selections
available (PROGRAM/MANUAL).
The PROGRAM Mode will run your testing routine according to the parameters
that have been entered within the testing parameters screen when the
TEST/RESET key is pressed. In most cases there will be a testing time
associated with the test mode unless the time has been selected to ∞ or the
cycle mode is ON.
The MANUAL Mode will run your testing routine according to the parameters
currently programmed into the instrument when the Test/Reset key is pressed.
However, there is no test time associated with the MANUAL Mode. The output is
continuous until the Test/Reset key is pressed again.
5.2 Initializing a Test in PROGRAM Mode
5.2.1 AC Output
When the AUTO RUN parameter in the System Parameters menu is set to
PROGRAM Mode the Set screen will be displayed as follows:
To initialize the test press the Test/Reset key and the LED for the key will
illuminate. The text “Set” on the set screen will turn to Dwell, in addition your soft
keys will change to include Meter, Cycle, Keypad, and Trig*.
*Only available if Transient parameter is set to OFF.
