Indicates the instrument is set up in Parallel mode
as the master (Option 08 only)
Indicates the instrument is set up in Parallel mode
as the slave (Option 08 only)
Indicates the instrument is set up in 1Φ3W mode
as L1-N (Option 08 only)
Indicates the instrument is set up in 1Φ3W mode
as L2-N (Option 08 only)
Indicates the instrument is set up in 3Φ4W mode
as Phase A (Option 08 only)
Indicates the instrument is set up in 3Φ4W mode
as Phase B (Option 08 only)
Indicates the instrument is set up in 3Φ4W mode
as Phase C (Option 08 only)
4.1.2 Security
Creating a Password
Creating a password prevents unauthorized access to the Lock parameters in the
System menu. Once a password has been created, lock functions will require
the password to access them.
Press and hold the <top> soft key while powering up the instrument, the Edit
Password screen should now be displayed. The display will appear as follows:
You may now type in the new password using the numeric keypad. Press the
Enter key to accept the new password or press the Esc key to escape. After you
type in your new password, you will be required to confirm your new password by
typing it again into the “Confirm Password” field. Press the Enter key to confirm
the new password or press the Esc key to escape.
If the password is set to 0, the Lock and Mem Lock parameters may be accessed
by editing Lock and Mem Lock soft keys in the System Parameters menu. In this
