MEASUREMENT (Total)
LINKING POLY-PHASE 3Φ4W
310XAC
320XAC
340XAC
360XAC
Voltage
Range
(A+B+C)/√3
Resolution
0.1 V
Accuracy
(A+B+C)/3 , Calculated and displayed to one significant digit
Frequency
Range
0.0 - 1000.0 Hz
Resolution
0.1 Hz
Accuracy
L
± 0.1 Hz @ 0.0 - 500 Hz
H
± 0.2 Hz @ 501 - 1000 Hz
Current (rms)
Range
(A+B+C)/3
Resolution
L
0.001 A
H
0.01 A
Accuracy
± (1% of reading +5counts) at 40~70Hz
± (1% of reading +5counts) at 70.1~500Hz, and output current (r.m.s) > 0.200A
± (1% of reading +5counts) at 501~1000Hz, and output current (r.m.s) > 0.300A
Power (W)
Range
A Power + B Power + C Power
Resolution
L
0.1 W
X
X
H
1 W
Accuracy
Calculated Value
Power Apparent
(VA)
Range
A VA + B VA + C VA
Resolution
L
0.1 VA
X
X
H
1 VA
Accuracy
Calculated Value
Power Reactive (Q)
Range
A VAR + B VAR + C VAR
Resolution
1 VAR
Accuracy
Calculated Value
Power Factor
Range
0 - 1.000
Resolution
0.001
Accuracy
Sum P / Sum VA, Calculated and displayed to three significant digits
MEASUREMENT (Total)
LINKING PARALLEL DC
310XAC
320XAC
340XAC
360XAC
Voltage
Range
0.0 - 420.0 V
Resolution
0.1 V
Accuracy
± (1% of reading + 2 counts) > 5 V
± (1% of reading + 5 counts) > 5 V
Current
Range
2
0.05 A - 26.00 A
0.05 A - 52.00 A
0.05 A - 104.00
A
0.05 A - 156.00 A
3
0.05 A - 39.00 A
0.05 A - 78.00 A
0.05 A - 156.00
A
0.05 A - 234.00 A
Resolution
0.01 A
Accuracy
± (1% of reading +
5 counts) x # of
Linked Units,
Current > 1.00 A
± (1% of reading +
5 counts) x # of
Linked Units,
Current > 1.00 A
± (1% of reading +
5 counts) x # of
Linked Units,
Current > 2.00 A
± (1% of reading +
5 counts) x # of
Linked Units,
Current > 3.00 A
Power (W)
Range
2
0 W - 2600 W
0 W - 25200 W
0 W -10400 W
0 W - 15600 W
3
0 W - 3900 W
0 W - 7800 W
0 W - 15600 W
0 W - 23400 W
Resolution
1 W
Accuracy
± (2% of reading + 5 counts) x # of Linked Units
