Clutch System Argo Service Manual
Ontario Drive & Gear Limited www.argoutv.com
PH.(519)- 662-2840 FAX (519)- 662-2421
CS-18
7. Lift o the moveable face to expose 500-0117-004 Spring, Drive and remove spring.
8. Remove 500-0121 Plate Moveable-Drive to expose 500-0119-003 Roller, Drive
weights.
IMPORTANT
All 600/650/700/850/950 ARGO models utilize 53g weights. 800 ARGO Models uti-
lize 35g weights. This can be distinguished by the larger hole in the 800 model clutch
rollers.
9. Check for any damaged rollers.
10. Slip o 500-0116 Cup, Spring Drive and Nylon Ring.
