ES-24
Electrical System Argo Service Manual
Ontario Drive & Gear Limited www.argoutv.com
PH.(519)- 662-2840 FAX (519)- 662-2421
2. Reinstall the V-Belt over both pulleys and tighten the adjustment bolt by turning it
clockwise. Do not overtighten the belt or allow it to be too loose. The V-belt should be
tightened enough that it deects no more then 1/8" with approx. 6 lbs. of force.
3. Once the belt is tensioned, re-tighten the bolt securing the alternator to the bracket.
Torque to 225.4 IN-LBS (Dry, Non-Lubricated Condition)
Dash Panel Switches And Gauge
NOTE
Switch or gauge replacement is best done with the dash panel removed from the vehicle.
1. Remove the four (4) screws securing the dash panel to the upper body.
2. Pull the dash panel away from the upper body to access gauges and switches.
Frontier Models
Aurora Models
