ES-23
Electrical System Argo Service Manual
Ontario Drive & Gear Limited www.argoutv.com
PH.(519)- 662-2840 FAX (519)- 662-2421
112-101 HHCS
108-76 WASHER
108-67 LOCKWASHER
112-22 HHCS
6. Disconnect the wiring from the alternator.
7. Using a 17mm Socket, locate and remove the two bolts securing the alternator to the
powerpack frame.
8. Remove the alternator.
Installing The Alternator
1. Install the alternator to the powerpack frame using the two HHCS M10x1,5x50mm
ZINC Bolts and Lockwashers. Torque to 37.2 FT-LBS (Dry, Non-Lubricated Con-
dition)
To Next Page
