EN-12
Engine System Argo Service Manual
Ontario Drive & Gear Limited www.argoutv.com
PH.(519)- 662-2840 FAX (519)- 662-2421
12. There are only four (4) bolts & lock washers securing the engine to the main frame
front & rear. Take note of which holes in the engine mounting frame are used for
installation later.
13. Remove all four (4) mounting bolts using a 9/16" socket and ratchet.
Lifting The Engine From The Vehicle
CAUTION
This procedure requires the use of an overhead hoist. Do NOT attempt to lift out by
hand. Ensure all components attached to the engine have been detached. This may
include any accessories that may be installed to the vehicle. Lift out slowly and care-
fully. If you wish to remove the muer from the engine before raising it out, you may
do so as an optional procedure. You may nd it easier to maneuver the engine up and
out with the muer removed, but it is not necessary. Protect the upper body with
heavy blankets to avoid any damage to the plastic!
WARNING
Ensure all hoist chains or belts are secure, and hooks are locked into place. Keep all
ngers and hands clear of the area from which the engine is being lifted.
