ES-13
Electrical System Argo Service Manual
Ontario Drive & Gear Limited www.argoutv.com
PH.(519)- 662-2840 FAX (519)- 662-2421
Removing The Tail Light
1. Drill out the rivets securing the rear tail light buckets to the upper body.
2. Pull the rear tail light bucket from the vehicle and unplug tail light wire connection.
3. Remove the nuts securing the tail light lens to the bucket and remove.
Installing The Rear Tail Light
4. Replace and secure the new lens into the bucket. Plug the lens back into vehicle wire
harness and reinstall the bucket to the upper body securing with the screws.
To Next Page
