Argo All 8X8 - Disassembling the Chain Tensioner System (Scissor Style )

Wheels, Axles & Chains Argo Service Manual
WA-16
10. Perform the servicing procedure, Installing the drive chain.
Disassembling The Chain Tensioner System (Scissor Style Chain Tensioner)
1. Release the spring tension on the tensioner arms and fold the upper tensioner block back
out of the way. Perform the servicing procedure, Removing A Drive Chain.
2. Locate and remove the Hair Pin from the Tensioner Pin.
NOTE
Depending on the location and orientation of the chain tensioner the hair pin will be located
inboard at the inner frame rail or outboard at the outer frame rail.
