EN-17
Engine System Argo Service Manual
Ontario Drive & Gear Limited www.argoutv.com
PH.(519)- 662-2840 FAX (519)- 662-2421
2. Slowly and gently lower the engine through the hood area. Some maneuvering is re-
quired as the engine does not necessarily drop straight in. Avoid damage to any vehicle
components as well as the upper body.
3. Align the engine mounted frame holes with the holes in the lower main frame and rein-
stall each of the four (4) HHCS 3/8-16x2.0 GR5 BNZ & 108-06 Lock washers. Secure
and torque each fastener to 31 FT-LBS (Dry, Non-Lubricated Condition)
4. Reconnect all engine sensor wiring between engine and main vehicle wire harness.
5. Reconnect engine connector plugs in the main wire harness located at the front of the
engine.
6. Reconnect fuel vent from fitting on engine.
7. Reconnect the intake hose from the air filter cannister.
8. Reconnect the throttle cable at the engine cable retainer.
9. Reconnect the ground cable at the engine.
10. Reconnect the fuel line and return fuel line from the engine.
11. Reconnect the wiring at the starter motor.
12. Locate the tailpipe assembly and reattach to the muffler with connecting springs.
13. Reinstall the heat deflector shield over the muffler.
14. Reconnect the battery positive (+) and negative (-) cables.
IMPORTANT
Reconnect the Positive (+) cable rst, followed by the negative cable
To Next Page
