Cav. Wire Colour Gauge Term. PN Seal Plug
A BK-01O
BK 18 1500-0105 7160-8234
B RDBL-01C
RD BL 18 1500-0105 7160-8234
C 7160-9465
D 7160-9465
E 7160-9465
F 7160-9465
LHSW-B
Left Hand Switch-B
6189-6171
BACK
A
B
Cav. Wire Colour Gauge Term. PN Seal
A GN-01C
GN 18 12077411 15324985
B BK-01M
BK 18 12077411 15324985
RLB
Righ Low Beam
12059183
B
A
Cav. Wire Colour Gauge Term. PN Seal
A VTWH-01A
VT WH 18 12048074 15324976
B BK-01E
BK 18 12048074 15324976
BCF
Brake Cooling Fan
12052641
1x 12052634 - BLUE SECONDARY LOCK - 2WAY
Cav. Wire Colour Gauge Term. PN Seal
A BKWH-01A
BK WH 18 1500-0110 7160-8234
B WHGN-01A
WH GN 18 1500-0110 7160-8234
C PKWH-01A
PK WH 18 1500-0110 7160-8234
SS
Speed Sensor
6180-3241
Cav. Wire Colour Gauge Term. PN
1 BK-01C
BK 18 1-160759-1
OUT-GND
12V outlet GND
154719-0
Cav. Wire Colour Gauge Term. PN Seal Plug
A GY-01A
GY 18 1500-0110 7160-8234
B GNRD-01B
GN RD 18 1500-0110 7160-8234
C RDYL-01A
RD YE 18 1500-0110 7160-8234
D 7160-9465
E BLRD-01B
BL RD 18 1500-0110 7160-8234
F 7160-9465
LHSW-A
Left Hand Switch-A
6180-6181
Cav. Wire Colour Gauge Term. PN
A ORBR-01J
OR BR 16 12034046
B BK-01Q
BK 18 12034046
C GY-01C
GY 18 12034046
D RD-01P
RD 16 12034046
KEY
Key Switch
12052856
1x 15324456 - Delphi TPA
Cav. Wire Colour Gauge Term. PN Plug
1 VTBK-01B
VT BK 18 3-1447221-3
2 BLWH-01B
BL WH 18 3-1447221-3
3 BK-01F
BK 18 3-1447221-3
4 4-1437284-3-PLUG
5 BLBR-01
BL BR 18 3-1447221-3
6 OR-01A
OR 18 3-1447221-3
7 WHGN-01A
WH GN 18 3-1447221-3
8 PKWH-01A
PK WH 18 3-1447221-3
9 BKWH-01A
BK WH 18 3-1447221-3
10 4-1437284-3-PLUG
11 4-1437284-3-PLUG
12 BL-01D
BL 18 3-1447221-3
13 BRGY-01A
BR GY 18 3-1447221-3
14 LTGNBK-0…
LTGNBK 18 3-1447221-3
15 YE-01C
YE 18 3-1447221-3
IP
Instrument Panel
XS018BA000
BACK
A
B
Cav. Wire Colour Gauge Term. PN Seal
A GN-01A
GN 18 12077411 15324985
B BK-01J
BK 18 12077411 15324985
LLB
Left Low Beam
12059183
BACK
A
B
Cav. Wire Colour Gauge Term. PN Seal
A BL-01A
BL 18 12077411 15324985
B BK-01K
BK 18 12077411 15324985
LHB
Left High Beam
12059183
BACK
A
B
Cav. Wire Colour Gauge Term. PN Seal
A BL-01B
BL 18 12077411 15324985
B BK-01L
BK 18 12077411 15324985
RHB
Right High Beam
12059183
Cav. Wire Colour Gauge Term. PN
1 ORWH-01
OR WH 18 1-160759-1
ST
Starter
154719-0
C
B
A
Cav. Wire Colour Gauge Term. PN Seal
A BK-02B
BK 18 12048074 15324976
B BLWH-01F
BL WH 18 12048074 15324976
C WH-01B
WH 18 12048074 15324976
TL-CON
Tail Light Connector
12110293
1x 12052845 - CREAM SECONDARY LOCK - 3WAY
B
A
Cav. Wire Colour Gauge Term. PN Seal
A GNWH-01A
GN WH 18 12048074 15324976
B BK-01D
BK 18 12048074 15324976
BPM
Bilge Pump
12052641
1x 12052634 - BLUE SECONDARY LOCK - 2WAY
B
A
Cav. Wire Colour Gauge Term. PN Seal
A BLBK-01A
BL BK 18 12048074 15324976
B BK-01T
BK 18 12048074 15324976
OP1
Winch
12052641
1x 12052634 - BLUE SECONDARY LOCK - 2WAY
Cav. Wire Colour Gauge Term. PN Seal Plug
1 12010300
2 VTOR-01A
VT OR 18 12077411 15324985
3 RD-01H
RD 18 12077411 15324985
4 RDBL-01A
RD BL 16 15363933 15324982
5 RD-01F
RD 16 15363933 15324982
6 RD-01G
RD 16 15363933 15324982
7 12010300
8 ORWH-01
OR WH 18 12077411 15324985
9 VTBK-01B
VT BK 18 12077411 15324985
10 BLWH-01D
BL WH 18 12077411 15324985
11 GNBL-01A
GN BL 16 15363933 15324982
12 BLGN-01A
BL GN 16 15363933 15324982
13 RDWH-01C
RD WH 16 15363933 15324982
14 RDWH-01D
RD WH 16 15363933 15324982
15 RDWH-01B
RD WH 16 15363933 15324982
16 RDGN-01B
RD GN 16 15363933 15324982
17 RDGN-01C
RD GN 16 15363933 15324982
18 BLRD-01C
BL RD 18 12077411 15324985
19 VTBK-01A
VT BK 18 12077411 15324985
20 VTGN-01A
VT GN 18 12077411 15324985
21 VTWH-01A
VT WH 18 12077411 15324985
22 BLBK-01A
BL BK 18 12077411 15324985
23 12010300
24 GNRD-01C
GN RD 18 12077411 15324985
Cav. Wire Colour Gauge Term. PN Seal Plug
25 ORBR-01B
OR BR 18 12077411 15324985
26 RD-01B
RD 14 12129493 15324982
27 RDYL-01A
RD YE 18 12077411 15324985
28 WH-01A
WH 18 12077411 15324985
29 RDOR-01A
RD OR 16 15363933 15324982
30 12010300
31 12010300
32 12010300
33 ORGY-01A
OR GY 18 12077411 15324985
34 BK-01A
BK 18 12077411 15324985
35 12010300
36 12010300
37 RDBL-01B
RD BL 14 12129493 15324982
38 BK-01V
BK 18 12077411 15324985
39 ORGY-01A
OR GY 18 12077411 15324985
40 VTOR-01A
VT OR 18 12077411 15324985
41 RDOR-01C
RD OR 16 15363933 15324982
42 12010300
43 12010300
44 12010300
45 RDBL-01D
RD BL 18 12077411 15324985
46 BK-01G
BK 18 12077411 15324985
47 12010300
48 BK-01N
BK 10 12077413 15324981
Cav. Wire Colour Gauge Term. PN Seal Plug
49 12010300
50 12010300
51 GNRD-01A
GN RD 18 12077411 15324985
52 GN-01B
GN 16 15363933 15324982
53 ORBR-01C
OR BR 18 12077411 15324985
54 RDGN-01A
RD GN 14 12129493 15324982
55 12010300
56 12010300
57 GNBL-01A
GN BL 16 15363933 15324982
58 BK-01Z
BK 18 12077411 15324985
59 RD-01M
RD 14 12129493 15324982
60 BK-01W
BK 18 12077411 15324985
61 ORBR-01A
OR BR 18 12077411 15324985
62 RDWH-01A
RD WH 14 12129493 15324982
63 BLRD-01A
BL RD 18 12077411 15324985
64 BL-01C
BL 16 15363933 15324982
65 ORBR-01D
OR BR 18 12077411 15324985
66 RDOR-01B
RD OR 14 12129493 15324982
67 RD-01A
RD 14 12129493 15324982
68 BK-01Y
BK 18 12077411 15324985
69 BLGN-01A
BL GN 16 15363933 15324982
70 BK-01U
BK 18 12077411 15324985
71 RD-01K
RD 14 12129493 15324982
72 BK-01X
BK 18 12077411 15324985
FP
Fuse Panel
1x 600-0041 - LABEL FUSE PANEL - INSTALL ON UNDERSIDE OF COVER
Cav. Wire Colour Gauge Term. PN
1 BLWH-01A
BL WH 18 1062-20-0122
2 WH-01C
WH 18 1062-20-0122
SW-B
Brake Switch
DTM06-2S
1x WM-2S - WEDGE LOCK 2WY PLUG
Cav. Wire Colour Gauge Term. PN Seal Plug
A 12059168
B 12059168
C YE-01A
YE 18 350851-1 15324976
D BRGY-01A
BR GY 18 350851-1 15324976
TM
Tach & MIL
12162102
1x 12047948 - BLACK SECONDARY LOCK - 4WAY
Cav. Wire Colour Gauge Term. PN
1 YE-01B
YE 18 61118-1
TACH
Tach
1-480351-0
C
B
A
Cav. Wire Colour Gauge Term. PN Seal Plug
A BLBR-01
BL BR 18 12048074 15324976
B 12059168
C BLWH-01E
BL WH 18 12048074 15324976
SW-PB
Park Brake Switch
12110293
1x 12052845 - CREAM SECONDARY LOCK - 3WAY
Cav. Wire Colour Gauge Term. PN
1
BK-01N
BK 10
42913-2
BK-01S
BK 10
BAT-
Battery (-)
1 RING
50mm- ES2000 - Heat Shrink Tubing Adhesive-Lined
1x RING TERMINAL - For M6 Stud
Cav. Wire Colour Gauge Term. PN
1
2 GNWH-01A
GN WH 18 0-0060295-2
3 VTGN-01A
VT GN 18 0-0060295-2
4
5
6
7 BK-01H
BK 18 0-0060295-2
8 BLWH-01C
BL WH 18 0-0060295-2
SW-BP
Bilge Pump Switch
VCH-01
Cav. Wire Colour Gauge Term. PN
1
RD-01I
RD 10
42913-2
RD-01N
RD 10
BAT+
Battery (+)
1 RING
50mm- ES2000 - Heat Shrink Tubing Adhesive-Lined
1x RING TERMINAL - For M6 Stud
Cav. Wire Colour Gauge Term. PN
1 LTGNBK-0…
LTGNBK 18 1-160759-1
OP
Oil Pressure
154719-0
Cav. Wire Colour Gauge Term. PN Plug
1 34345-0001
2 34345-0001
3 OR-01A
OR 18 33012-3002
4 BK-02A
BK 18 33012-3002
FP-CON
Fuel Pump and Sender
33472-4001
Cav. Wire Colour Gauge Term. PN
1 GY-01B
GY 18 1-160759-1
GK
Ground Kill
154719-0
Cav. Wire Colour Gauge Term. PN
1 VTBK-01A
VT BK 18 1-160759-1
OUT-POS
12V outlet GND
154719-0
PART NUMBER 600-0246 DESCRIPTION: HARNESS, MAIN
