Table B-18 shows the timing parameters for the FPU output signals.
Clock uncertainty 45% ATCADDRPTY
Clock uncertainty 45% B0TCEN0
Clock uncertainty 45% B0TCEN1
Clock uncertainty 45% B0TCADDR[22:3]
Clock uncertainty 45% B0TCBYTEWR[7:0]
Clock uncertainty 45% B0TCSEQ
Clock uncertainty 45% B0TCDATAOUT[63:0]
Clock uncertainty 45% B0TCPARITYOUT[13:0]
Clock uncertainty 45% B0TCACCTYPE[2:0]
Clock uncertainty 45% B0TCWE
Clock uncertainty 45% B0TCADDRPTY
Clock uncertainty 45% B1TCEN0
Clock uncertainty 45% B1TCEN1
Clock uncertainty 45% B1TCADDR[23:0]
Clock uncertainty 45% B1TCBYTEWR[7:0]
Clock uncertainty 45% B1TCSEQ
Clock uncertainty 45% B1TCDATAOUT[63:0]
Clock uncertainty 45% B1TCPARITYOUT[13:0]
Clock uncertainty 45% B1TCACCTYPE[2:0]
Clock uncertainty 45% B1TCWE
Clock uncertainty 45% B1TCADDRPTY
Table B-18 FPU output port timing parameters
Output delay
minimum
Output delay
maximum
Signal name
Clock uncertainty 60% FPIXC
Clock uncertainty 60% FPOFC
Clock uncertainty 60% FPUFC
Clock uncertainty 60% FPIOC
Clock uncertainty 60% FPDZC
Clock uncertainty 60% FPIDC
Table B-17 TCM interface output ports timing parameters (continued)
Output delay
minimum
Output delay
maximum
Signal name
