ARRI ALEXA Series User Manual

Technical Data are subject to change without notice.CAMERA DIMENSIONS – Version 2012-03
ALEXA M
Head with HEAD-PLATE-2 Right Image Plane
Head with HEAD-PLATE-2 Top Image Plane
Optical Center
74.5 mm
2.93”
36 mm
1.42”
36 mm
1.42”
85 mm
3.35”
78 mm
3.07”
for 15 mm RODSfor 15 mm RODS
2nd 15 mm RODS-Adapter (optional)
43 mm
1.69”
40 mm
1.58”
43 mm
1.69”
40 mm
1.58”
30 mm
1.18”
30 mm
1.18”
16 mm
0.63”
12.7 mm
0.5”
12.7 mm
0.5”
9.5 mm
0.37”
29.5 mm
1.16”
16 mm
0.63”
49.5 mm
1.95”
3 mm
0.12”
8.5 mm
0.34”
41 mm
1.61”
66 mm
2.6”
85 mm
3.35”
16 mm
0.63”
M4 (4 mm deep) M4 (4 mm deep)
UNC 3/8“–16 (10 mm deep)
61.5 mm
2.42”
M6 (3.5mm deep)
70.9 mm
2.8”
70.9 mm
2.8”

ARRI ALEXA Series Specifications

General

Dynamic Range	14+ stops
Resolution	4.5K (ALEXA LF), 6.5K (ALEXA 65)
Recording Formats	ARRIRAW, Apple ProRes
Lens Mount	PL mount
Viewfinder	Optional EVF (Electronic Viewfinder)
Sensor Size	Super 35 (most models), Large Format (ALEXA LF, ALEXA 65)
ISO Range	EI 160 - EI 3200 (Base ISO 800)
