ARRI ALEXA Series User Manual

Main Controls 99
6. Press the HOME button or BACK button to exit and output a live
image over the output paths.
Figure 70: PLAY screen
PLAY screen buttons
STEPSIZE Toggle the scrub step size between one frame and
one second.
CIRCLE
CLIP
Press to mark the clip as a circle take. This
information will be embedded in the metadata of
the clip.
+10% Advance the current clip by ten percent of the clip
duration.
-10% Rewind the current clip by ten percent of the clip
duration.
Note: Recorded clips do not contain the surround view portion of the EVF-1 or
MON OUT image. When playing back clips, the surround view portion will not
be visible.
The jogwheel can be used to scrub through the paused clip. The scrub
stepsize is shown in the lower middle section of the screen.
Additional PLAY screen information:
 clip name
 playback progress bar with current playback position in time and
total clip duration
 playback timecode
Note: Do not eject media during playback.

ARRI ALEXA Series Specifications

General

Dynamic Range	14+ stops
Resolution	4.5K (ALEXA LF), 6.5K (ALEXA 65)
Recording Formats	ARRIRAW, Apple ProRes
Lens Mount	PL mount
Viewfinder	Optional EVF (Electronic Viewfinder)
Sensor Size	Super 35 (most models), Large Format (ALEXA LF, ALEXA 65)
ISO Range	EI 160 - EI 3200 (Base ISO 800)
