125
To remove the film gate
• Switch off the camera’s main switch and disconnect
the camera from the power supply before removing
the film gate.
• Turn the knurled knob ➪ photo on the movement
until its marking matches that on the movement block.
• Turn the movement locking lever ➪ photo towards
the “OPEN” position to swing the movement block away
from the film gate.
• Press the film gate locking lever ➪ photo towards the ma-
gazine throat assembly and swing the film gate ➪ photo
towards the movement block, pressing lightly on the
lower end of the film gate and taking care that the film
gate does not hit the movement block.
• Take hold of the film gate by the filter holder ➪ photo,
lift it up and remove.
To clean the film gate
• Remove the layer of emulsion from the film gate with a
plastic rod (e.g. an ARRI film gate cleaner). Under no
circumstances use hard or metal objects.
• When cleaning, pay particular attention to the area
opposite the film guides of the movement if film stock
with a strong tendency to build up emulsion (e.g. b/w
stock) is being used.
Inserting the film gate
Warning: It is absolutely essential to ensure that
the connecting surfaces are free of dust and
debris (e.g. film chips) in order to guarantee
the accuracy of the film channel.
• Check that the film gate and the film gate shaft are com-
pletely free of dust and dirt.
• Take hold of the film gate by the filter holder and
place onto the film gate shaft from above.
• Check that the film gate is correctly seated on the
shaft.
• Press the film gate locking lever ➪ photo towards the
magazine throat assembly and push the film gate
forwards to the correct position.
• Ensure that the film gate locking lever ➪ photo
swings back completely.
Swinging the movement block forwards when
the film gate is not correctly in place can cause
damage to the camera!
Maintenance
