60
Overview of Display Symbols
Symbol Meaning
glows The display is in Mode 1.
bat glows Battery voltage too low for the set frame rate
≤ 130 fps and voltage < 20.6 V
130-150 fps rampspeed St and LO and voltage < 24 V
130-150 fps rampspeed HI and voltage < 26.5 V
asy glows Asynchronous operation
(camera is not running at set frame rate)
blinks Movement/shutter not synchronous
end glows film end
fps blinks The magazine is not suited to the set frame rate, or
ESU is connected
and no sync-frequency is available
PROG glows The stored program is activated and can be started while
the camera is running by depressing the "PROG"-button.
blinks The activated program cannot be run with the set values:
e. g.: incorrect magazine for the frame rate set in the
program, or battery voltage too low for the frame rate set
in the program.
Symbol Meaning
blinks The shutter is mechanically locked in electronic operation
or
the electronic shutter function is switched off.
The symbol blinks and the operation control
indicator glows
red although the shutter is not locked:
The electronic shutter adjustment is defective –
the electronic shutter adjustment can be switched off
see chapter 7.
R glows Reverse operation is switched on.
TC glows TC-generator is switched on and set.
blinks TC-generator is switched on
during running: no recording
during standby: the last synchronization
was over 8 hours ago
additional acoustic warning,
see also TC warning display.
