59
1st Display Line 2nd Display Line Adjustment Possibility
Mode 5 time code user bits time code user bits time code user bits can only be set via
time code warnings the CCU or externally
Mode 6 volume of the acoustic warning signal TCS-value or warning signal on / off
voltage of the time code buffer battery (V) volume
TCS-value
Mode 7 stored program settings frame rate (fps) setting of the shutter angle
set shutter angle stored program settings
Mode 8 rampspeed -capping shutter state setting of ramping and runup speed
in motion control modes:
- transport encoder position
(modulo 2000)
- shutter encoder position
(modulo 2000)
- motion control exit
error code
- software version
Mode 9 EC (external control) external control mode selection of external control mode
Camera Operation
