23
Mains Unit NG 12/24 R
Use of the mains unit is recommended for filming in the studio
and when using electronic accessories with a high power
consumption. It is suitable for frame rates up to 130 fps.
• First check that the correct mains voltage is set on the
mains unit.
• Ensure that the main switch on the camera is off.
• Set the voltage switch on the mains unit to 24 V.
• Plug the battery cable KC 20S or the spiral battery
cable KC 29S into the power supply socket on the
camera and into the 24 V-socket on the mains unit.
Mains Unit NG 12/26 R
Use of the mains unit is recommended for filming in the studio
and when using electronic accessories with a high power
consumption. It is suitable for frame rates up to 150 fps.
• First check that the correct mains voltage is set on the
mains unit.
• Ensure that the main switch on the camera is off.
• Set the voltage switch on the mains unit to 26 V.
• Plug the battery cable KC 20S or the spiral battery
cable KC 29S into the power supply socket on the
camera and into the 26 V-socket on the mains unit.
Note: The NG 12/24 R can easily be upgraded to an
NG 12/26 R at an ARRI service center.
Power Supply
