17
Grip System
The multipurpose grip system on the ARRIFLEX 435/435ES
guarantees highest stability through its fixed connection to
the camera body and provides numerous possibilities for
attaching accessories. Five 3/8" inner threads allow
attachment in diverse positions ➪ photo.
Attaching Additional Handgrips
Additional handgrips can be screwed onto the grip system
in various positions as required. A safety mechanism in the
handgrip prevents automatic loosening. This mechanism is
activated by screwing in the handgrips tightly.
Before screwing in the handgrips, make sure
that the 3/8" threaded bolt is completely
screwed out of the handgrip.
Removing the Grip System
In order to minimize camera height, the entire grip system
can be removed.
• First remove the magazine.
• Loosen both the hexagon screws ➪ photo in the strut
and pull the grip system ➪ photo upwards.
To attach the grip system, proceed in the reverse order.
Installation
grip system
hexagon screws
