58
Overview of Display Modes
Mode 1 is displayed:
after switching on the camera,
after depressing the “RUN”-button or
30 seconds after the last operation.
Mode 4 and 5 can only be selected
if the functional expansion module is attached.
1st Display Line 2nd Display Line Adjustment Possibility
Mode 1 total exposed film counter (m/ft) or frame rate (fps) or selection of a standard frame rate
take counter (m/ft) or ESU, SU in standby and configuration of the 1st display line
mirror shutter angle frame rate (fps) while running
take counter is replaced by frame counter (external control connected)
in motion control mode or Pr if a program is activated
Mode 2 programmed frame rate (PS) programmed frame rate (fps) programmed frame rate
ESU, SU – external control connected current frame rate if a program (forwards / reverse)
current shutter angle if a program is activated is activated
Mode 3 total exposed film counter (m/ft) or power supply voltage (V) configuration of the film counter
take-counter (m/ft) unit of measurement (m/ft)
take counter is replaced by frame counter
in motion control mode
Mode 4 time code time (hours, minutes) time code time (seconds, frames) time code on / off
time code time can only be set via the
CCU or externally
Camera Operation
