33
locking mechanism
7. Camera Body
Electronically Adjustable Mirror Shutter
The mirror shutter on the ARRIFLEX 435 Advanced can be
electronically adjusted from 11.2° to 180° when the
camera is running as well as in standby.
Note: The electronically adjustable mirror shutter is also
equipped with an adjustment mechanism that
allows mechanical adjustment. The electronic
mirror shutter function must then be switched off.
Before electronically adjusting the mirror shutter,
check that the shutter locking mechanism is in
the “LOOSE” position
➪
photo. Adjusting the
shutter angle while the shutter is locked could
cause damage to the camera!
Camera Body
locking mechanism
locked
locking mechanism
unlocked
