25
24 V Accessories
The RS-socket supplies the same voltage as the
camera power supply. Voltages over 32 V will
be limited to 32 V. In this case, the allowable
continuous current is 2 A maximum.
Ensure that the accessories to be used are
suited to the available voltage!
24 V accessories are normally attached to the RS-socket
➪ photo. At 24 V, the available continuous current is
3 A maximum, the peak load 5 A.
Overload Display
If the current drawn at the accessory sockets exceeds the
allowable maximum, a safety circuit interrupts the power
supply and a red warning LED lights up ➪ photo.
Power Supply
RS-socket
overload
warning LED
