Overview 46
What is it ?
The newly developed Battery Mounting System enables extremely flexible use and attachment
of different battery types (B-Mount, V-Mount & G-Mount) on the TRINITY generation 1 and 2 and
ARTEMIS generation 2.
How does it work?
The battery holder system consists of a base module with a the rod clamp mechanism to which three
different battery holders can be attached quickly and easily.
The newly developed clamping mechanism allows the BMS to be mounted on the 19 mm rods of
the new Battery Hanger Gen. 2 (BAH-2) as well as on the 18 mm rods of the of the first generation
TRINITY Battery Hanger.
What problems does it solve?
The new clamping mechanism allows the BMS to be attached directly to the desired position.
The cumbersome pushing of the mounts onto the rods is no longer necessary.
Which combinations are possible?
There are currently three different battery mounts available to be used with the Battery Hanger Modul
Gen. 2 / BHM-2:
V-Mount (12V), Gold Mount (12V) and B-Mount (24V).
There are two versions of the BMS:
BMS-2 with 4pin LEMO 2B for the Battery Hanger Gen. 2
for Battery Hanger Modul Gen. 2 BHM-2 K2.0039300
BMS-1 with 3pin LEMO 1B for the TRINITY
Battery Hanger Gen. 1 / BHM-1 K2.0037707
The BMS-2 can be combined with the:
B-Mount for BMS-2 K2.0040284
Gold Mount for BMS-1 / BMS-2 K2.0040285
V-Mount for BMS-1 / BMS-2 K2.0040286
The BMS-2 transmits status information of the batteries as soon as the batteries offer data
communication.
The BMS-1 can be combined with the:
Gold Mount for BMS-1 / BMS-2 K2.0040285
V-Mount for BMS-1 / BMS-2 K2.0040286
The BMS-1 does not transmit any status information of the batteries.
BMS-1 can NOT be used with the B-Mount (24V) battery mount.
