Installation and Operation 63
8.4 Master Grip Trinity Installation and Operation
8.4.1 Mounting the Master Grip TRINITY on the Gimbal
Gimbal Mounting Bracket
1. Before you begin, make sure the gimbal handle extension is also
attached.
2. Open the clamp lever of the Mounting Bracket
3. Place the Master Grip TRINITY on the gimbal grip as close as pos-
sible to the bend.
4. When you have reached the desired position, tighten the clamp wing
nut.
