2.2.2. Rackmounting the AudioFuse 16Rig
Attach the rack ears in the configuration shown above, and the AudioFuse 16Rig is ready
to slot into your rack. In this configuration, you won't need the rear feet or rubber pads, so
leave them in the box in case you want to rack mount the unit some day.
We recommend rackmounting the AudioFuse 16Rig with an open rackspace above or below it, to
assist with keeping the unit cool during operation.
AudioFuse 16Rig configured for rackmounting
Arturia - User Manual AudioFuse 16Rig - Setting Up The Hardware 7
