Channel Computer Input (REC) Computer Output (Playback)
17 ADAT In 1 ADAT Out 7
18 ADAT In 2 ADAT Out 8
19 ADAT In 3 ADAT Out 9
20 ADAT In 4 ADAT Out 10
21 ADAT In 5 ADAT Out 11
22 ADAT In 6 ADAT Out 12
23 ADAT In 7 ADAT Out 13
24 ADAT In 8 ADAT Out 14
25 ADAT In 9 ADAT Out 15
26 ADAT In 10 ADAT Out 16
27 ADAT In 11 USB Playback
28 ADAT In 12 USB Playback
29 ADAT In 13 USB Playback
30 ADAT In 14 USB Playback
31 ADAT In 15 USB Playback
32 ADAT In 16 USB Playback
33 Loopback In (Left) Loopback Out (Left)
34 Loopback In (Right) Loopback Out (Right)
10.1.0.2. Audio Mapping at 88.2 / 96 kHz sampling rates:
Channel Computer Input (REC) Computer Output (Playback)
1 Front/Rear In 1 Speakers/Headphones Left
2 Front/Rear In 2 Speakers/Headphones Right
3 Front/Rear In 3 Front/Rear Out 3
4 Front/Rear In 4 Front/Rear Out 4
5 Rear In 5 Rear Out 5
6 Rear In 6 Rear Out 6
7 Rear In 7 Rear Out 7
8 Rear In 8 Rear Out 8
9 Rear In 9 Rear Out 9
10 Rear In 10 Rear Out 10
Arturia - User Manual AudioFuse 16Rig - Appendices 69
