Handset Configuration
CONFIGURATION MANUAL
Ascom d83 DECT Handset
• L1- L4: The four last valid location IDs. If the handset is in the range of several LF location devices, the
location ID with highest difference between the measured signal strength and threshold value is
regarded as the current location (L1). This means that only one current location exists, even if several
valid locations have been received.
• t1 - t4:The elapsed time in seconds since the locations L1 -L4 were received, respectively. It stops
counting when it reach its maximum value of 9999 seconds.
LF Location Indications
When the LF Location info screen is opened, the handset can be configured to provide additional
indications to the support engineer as the handset is carried into a valid location. A beep indication can be
activated to indicate when valid locations are received. The activation parameters that can be configured
via the WinPDM/Device Manager are as follows: Location → Common → Indicate location with beep.
• Off - The beep indication is turned off
• Beep on new - The handset beeps when it receives a new valid location. A location is considered as
“new” when the location ID is changed for the current location.
• Beep always - The handset beeps when it is receives a valid location.
Location → Common → Indicate location with LED.
• Off - The LED indication is turned off.
• Blink always - The LED blinks when the handset receives a valid location.
Location Information during Call
When the Admin menu is activated and LF location is enabled, the LF location information screen can be
accessed during a call by pressing the soft key More and select Location info.
5.24 Special Location
A special location is a valid location received from a location device that triggers the handset to automati-
cally send the location information list to the system. A special location is marked with an asterisk (*) next to
location ID in the location info list. To prevent the system from being overloaded, a special location that has
already been received in the last three seconds will not be sent to the system again. The special location
feature is managed from the WinPDM/Device Manager in the following way:
1. Select Location → Common → Special location.
2. In the Special location drop-down list, select one of the following:
− On- Turns the special location feature on.
− Off - Turns the special location feature off.
5.25 All Location Data
All location data is shown in the All Location info screen in the handset. The handset stores the four last
received location IDs and the time that has elapsed since the location IDs were received. DECT locations
are marked with D, BLE locations are marked with B, LF locations are marked with L, while IR locations are
marked with I. To configure the handset to provide all location data, perform the following procedure:
1. Press the Menu soft key.
2. Select Calls.
3. Select Admin menu.
36
TD 93426EN / 28 January 2022 / Ver. C
