Handset Configuration
CONFIGURATION MANUAL
Ascom d83 DECT Handset
5.45 Profiles
5.45.1 User Profiles
An own profile can be setup for incoming calls, message alerts, message volume, vibrating alerts, key
sound etc. This can be useful when there are many users on the same handset who want different sound
profiles. It can also be used for temporarily settings, for example while in a meeting, incoming calls should
be silent.
1. Select User Profiles → User Profile X (where X represents 1 - 4).
2. In the Name text field, enter the name of the profile.
The name is visible in the handset and becomes a selectable option in User Profiles → Active Profile.
3. Select the settings to be edited. For example Sound and alerts, Soft keys etc.
4. If required, select the profile to be activated in the handset by selecting User Profiles → Active Profile.
Profiles can also be configured via the handset menu. Refer to the User Manual, Ascom d83 DECT Handset,
TD 93434EN.
5.45.2 System Profiles
This feature is only applicable for some handset variants, see 1.1 Functionality Matrix, page 1.
A system profile can be setup to force a handset to use certain settings that the user is unable to modify.
The system profile is set up in two steps:
1. Create sub groups.
2. Create system profile using the predefined sub groups.
5.45.2.1 Configure Presence settings group (sub group)
1. Select System Profiles → System Profiles Sub Groups → Presence groups → Presence group X.
2. In the Message absence drop-down list, select one of the following:
− On - When a handset receives a message, it indicates that it is absent. The message can be
redirected to another destination and is system dependent.
− Off - The message absence is disabled.
3. In the Name of group field, enter a descriptive name.
5.45.2.2 Configure Alarm Settings Group (sub group)
1. Select System Profiles → System Profiles Sub Groups → Alarm settings group → Alarm settings X.
2. In the Name of group field, enter a descriptive name.
3. Select System Profiles → System Profiles Sub Groups → Alarm settings group → Alarm settings X →
Common.
− Stored alarm data - Information that shall be sent along an alarm (for example a handset’s location).
− Indicate triggered alarm with vibrator.
− Indicate triggered alarm with LED.
− Indicate triggered alarm with beeper signal.
If any of the alarm triggers are set to No, no indication is shown for that trigger when an alarm
is sent or received.
56
TD 93426EN / 28 January 2022 / Ver. C
