CONFIGURATION MANUAL
Ascom d83 DECT Handset
Handset Configuration
The Admin menu is only visible if the Admin menu is activated. To activate the Admin menu,
see 6.1.1 Activating the Admin Menu, page 64.
4. From the Admin menu, select Location info.
5. Select All Location info. All location information is displayed in the handset display as shown in Figure
7. All Location Information, page 37.
Figure 7. All Location Information
5.26 Poll Location
A system or application can request a location of a handset. When location of the handset is requested, the
handset sends its exact location (DECT or LF or BLE or IR location enabled), or an approximate location
(Base Station positioning enabled) depending on the set parameters in the handset.
If DECT or LF or BLE or IR location is enabled, the handset sends the four last received location IDs together
with the time since they were received. See also 5.21 DECT Location, page 30 or 5.22 IR Location, page 32.
If Base Station positioning is enabled, the handset sends the best-rated Base Station ID together with the
time since it was received. See also 5.19 Base Station Positioning, page 27.
5.27 Common Alarm Settings
The support for this feature is dependent on that model of handset that is used. For more
information, see 1.1 Functionality Matrix, page 1.
In a template or Number in WinPDM/Device Manager, the parameters for activation are found at: Alarm →
Common.
Parameters in the current version are:
• Stored alarm data
Information that is sent with an alarm (for example a handset’s location)
• Indicate triggered alarm with vibrator
If the parameter “Silent alarm” is set, no indication is shown when an alarm has been sent or
received.
TD 93426EN / 28 January 2022 / Ver. C
37
