ASCOM i62 VoWiFi User Manual

TD 92599EN
1 September 2011/ Ver. B
User Manual
Ascom i62 VoWiFi Handset
15
IMPORTANT: The VoWiFi Handset may retain small metal objects around the microphone or
earpiece region.
Case
The plastic cover parts are made of durable PC/ABS material.
The VoWiFi Handset has the enclosure protection IP44 and it also fulfils IEC 60068-2-32,
procedure 1, which makes it drop proof from 1 meter onto concrete. Ascom approves 12
drops from 1.5 metre.
Antenna
The antenna is integrated inside the VoWiFi Handset.
Display
The display is an illuminated 28 x 35 mm, TFT display.
Keypad
While not in use, the keypad should be locked to prevent pressing a key accidentally.
Loudspeaker
The VoWiFi Handset has a separate loudspeaker for the loudspeaking function. It is placed
on the back side of the VoWiFi Handset.
Microphone
The microphone is placed on the front bottom side of the VoWiFi Handset.
Clip
There are two different belt clip options to the VoWiFi Handset; a hinge-type clip (standard),
and a swivel-type clip. See 15 Troubleshooting on page 69, or 14.3 Attach the Swivel-type
Clip on page 68. Use the clip to attach the VoWiFi Handset to a pocket, belt, or similar. It is
also possible to use the VoWiFi Handset without any clip on, see 14.4 Attach Cover for No
Clip on page 68.
Battery
The battery is a rechargeable Li-Ion battery, placed under a battery cover. See 14.1.4
Replace the Battery on page 66.
The battery is fully charged within 2.5 hours. See 14.1.2 Charge the Battery on page 66.
The battery can be charged separately with a special battery charger. See 14.1.3 Charge
Spare Batteries on page 66.
