ASCOM i62 VoWiFi User Manual

TD 92599EN
1 September 2011/ Ver. B
User Manual
Ascom i62 VoWiFi Handset
14
2 Earpiece speaker
3 Volume button (up)
To increase the earpiece speaker, headset, and the loudspeaker volume.
4 Volume button (down)
To decrease the earpiece speaker, headset, and the loudspeaker volume.
5 Mute and PTT button
To turn on/off audible signals in standby mode, or silencing the ring signal at
incoming call. During a call, a long press on the button changes between
microphone on/off. Same function as (13) Sound off key.
To open the microphone during a Push-to-Talk (PTT) group call. The microphone
is open as long as the button is depressed.
6Soft keys
The three Soft keys can be pre-programmed, see 9.6.1 Define Soft Keys on page
52, or used with the GUI. The function of each Soft key is indicated by text in the
display just above the keys.
7 Call key
To answer a call, to pre-dial a number, and used as a short cut to the Call list.
8Five-way navigation key
Navigation key with Left, Right, Up, Down, and Confirmation (in the middle). It is
also possible to program these keys for short cuts, except the middle key. The
is by default a short cut to the Inbox, and is a short cut to Call contact. See also
9.6.3 Define Navigation Key on page 53.
9 Voice mail access
a
A quick access to the VoWiFi Handset’s Voice mail by long press. See also 11.1
Voice Mail on page 62.
10 Key lock and upper/lower case
Combined key lock to lock the keypad and upper/lower case. This key is to lock
the keypad in combination with the soft key “Lock”. This key is also for switching
between upper/lower case and digits.
11 Microphone
12 Space
To add space between text.
13 Sound off key
To turn on/off audible signals in standby mode, or silencing the ring signal at
incoming call. During a call, a long press on the key/button changes between
microphone on/off. Same function as (5) Mute button.
14 Tactile indicators
There are two tactile indicators to indicate the centre of the key pad.
15 End key and On/Off
Combined button; to end a call, to return to standby mode, and to switch the
VoWiFi Handset on/off by long press.
16 Color display
The full graphic type display is 176 pixels wide and 220 pixels high. The display
has multiple colors and backlighting.
17 Headset connector
The headset connector is used to connect a headset. It is protected against dust
by using the headset connector cover.
18 LED
Indicates incoming call, messaging, low battery, and charging.
a. This feature is system dependent.
