TD 92599EN
1 September 2011/ Ver. B
User Manual
Ascom i62 VoWiFi Handset
20
3.2.2 Rack Charger
The rack charger is used for charging up to six VoWiFi Handsets at the same time.
Refer to the Installation and Operation Manual, CR3 Charging Rack, TD 92480EN.
3.2.3 Battery Pack Charger
The battery pack charger (CR4) is used for charging up to six spare batteries.
Refer to the Installation Guide, CR4 Battery Pack Charger, TD 92724EN.
3.2.4 Clip
Note: It is possible to use the VoWiFi Handset without any clip on, see 14.4 Attach Cover for
No Clip on page 68.
Note: The belt clips cannot be used if the VoWiFi Handset shall be placed in a case. See 3.2.6
Leather Casing on page 20 for more information.
There are two belt clips available:
• Hinge-type clip
To prevent the VoWiFi Handset from slipping out of for example pocket or belt, see 15
Troubleshooting on page 69.
•Swivel-type clip
To be able to rotate without slipping out from for example pocket or belt, see 14.3
Attach the Swivel-type Clip on page 68.
3.2.5 Security Cord
The security cord is 800 mm long. It is attached directly to the VoWiFi Handset.
3.2.6 Leather Casing
The leather casing is especially designed for the VoWiFi Handset. The casing comes with a
swivel type belt clip, and the VoWiFi Handset is fully operational while placed in the casing.
3.2.7 Headset
A headset is recommended if the VoWiFi Handset is frequently used and/or if the user
wants to have both hands free. The headset comes in three versions; microphone integrated
in the cable, microphone on a boom and hearing protection. It is also possible to use any
headset with a 2.5 mm connector and configure parameters for the headset using the user’s
headset profile.
In order to achieve optimal audio quality with the different headset types it is recommended
to select the corresponding headset profile. See 9.8.1 Headset on page 60 for more
information.
