Page #82 background image
76
7.2.2. GPIB Address
Each device on the GPIB (IEEE-488) interface must have a unique address. You can
set the address of the 620L to any value between 0 and 30. The address can only be
set from the front panel. The address is stored in non-volatile memory and does not
change when the power has been off or after a remote reset.
The address is set to 9 when the instrument is shipped from the factory.
7.3. Interface Functions
The capability of a device connected to the bus is specified by its interface functions.
These functions provide the means for a device to receive, process, and send
messages over the bus. The interface functions are listed in the chart below.
GPIB 488.1 INTERFACE FUNCTIONS
INTERFACE
FUNCTION
SUBSET
DESCRIPTION
Source Handshake
SH1
Complete Source handshake capability
Acceptor Handshake
AH1
Complete Acceptor handshake capability
Talker
T6
Talker functions (unaddress if MLA)
Listener
L4
Listener functions (unaddress if MTA)
Service Request
SR1
Complete Service request capability
Remote Local
RL0
No remote/local capability
Parallel Poll
PP0
No parallel poll capability
Device Clear
DC1
Complete Device clear capability
Device Trigger
DT0
No device trigger capability
Controller
C0
No controller capability
Electrical Interface
E2
Three-state drivers
Controllable Items
Test and Reset control.
Setting of test parameters for tests.
Reading of instrument status and test results.
Data Codes
ASCII
Delimiter
NL (+ EOI)
7.4. USB/RS-232 / GPIB Interface Command List
7.4.1. Echo and Response Considerations
USB/RS-232 Responses
The USB/RS-232 bus will automatically send any response back to the controller's
input buffer.
