Associated Research 620L User Manual

49
Inserting Tests
From the Setup Tests screen scroll the highlighted area to the step in the sequence
where you would like to insert a test. Press the “Add” soft key. The highlighted area
will blank and the test that was originally at this step in the sequence, as well as all of
following steps, will increment. You may now select the type of test you wish to insert
from the soft key menu.
Inserting a Text Prompt
Refer to section 4.3.4. Prompt for a detailed description of inserting text prompts.
4.5.2. Line Leakage Test
From the Setup Tests, Tests Selection screen press the “Line Leakage” soft key. The
Line Leakage Parameter Setting screen will now be displayed. The Line Leakage
Parameter Setting screen will appear as follows:
From the Line Leakage Parameter Setting screen, the following parameters may be
controlled: Leakage-HI, Leakage-LO, Voltage-HI, Voltage-LO, Delay Time, Dwell
Time, Neutral, Reverse, Ground, Measuring Device, Probe, and More. Pressing the
“More” soft key will bring up additional parameters: Leakage, Extended Meters,
AC/DC, Ranging Mode and Continuous.
