Asycube - Asyril SA
Programming Guide
64/83
The transition ERROR->DONE can be controlled by setting both triggers to 0.
HR_PLATFORM_REMAINING_TIME
This Holding Register gives the remaining time of the platform vibration. During a
vibration, the value decreases over time until it reaches 0.
Note: A value of 32767 means that the remaining time is greater than 32767ms.
Note: Just before the vibration starts, during the amplifier start up, the value is
different than 0 but can be strange. Similarly, during a continuous vibration, the
value stays different than 0 but can be strange.
This Holding Register gives the status of either the hopper vibration trigged with
HR_HOPPER_VIBRATION_TRIG or the hopper feeding trigged with
HR_HOPPER_FEEDING_TRIG.
The transition DONE->BUSY occurs on the trigger rising edge if the data is
correct.
The transition DONE->ERROR occurs on the trigger rising edge if the data is
incorrect (e.g. index is out of range).
The transition BUSY->DONE occurs as soon as the vibration ends.
The transition BUSY->ERROR occurs if an Internal Modbus communication
error (See Section 6.4.2) before the vibration starts.
The transition ERROR->DONE can be controlled by setting both triggers to 0.
This Holding Register gives the remaining time of the hopper vibration. During a
vibration, the value decreases over time until it reaches 0.
Note: A value of 32767 means that the remaining time is greater than 32767ms.
Note: Just before the vibration starts, during the amplifier start up, the value is
different than 0 but can be strange. Similarly, during a continuous vibration, the
value stays different than 0 but can be strange.
