Programming Guide
© Copyright Asyril S.A.
000.101.572
Version : A1
74/83
Address
(decimal)
Holding Register name
Read/
Write
Data Range
Comments
N/A for the Asycube 50 and 80.
1536+22
HR_HOPPER_ANALOG_OUTPUT1
W
This value is written to the corresponding parameter in Section 4.3.
N/A for the Asycube 50 and 80.
1536+23
HR_HOPPER_DIGITAL_OUTPUT2
W
This value is written to the corresponding parameter in Section 4.3.
N/A for the Asycube 50 and 80.
1536+24
HR_HOPPER_ANALOG_OUTPUT2
W
This value is written to the corresponding parameter in Section 4.3.
N/A for the Asycube 50 and 80.
1536+25
HR_HOPPER_VIBRATION_AMPL
W
This value is written to the corresponding parameter in Section 4.3.
Only applicable for the Asycube 50 and 80.
1536+26
HR_HOPPER_VIBRATION_FREQ
W
This value is written to the corresponding parameter in Section 4.3.
Only applicable for the Asycube 50 and 80.
1536+27
HR_HOPPER_VIBRATION_WAVEFORM
W
This value is written to the corresponding parameter in Section 4.3.
Only applicable for the Asycube 50 and 80.
1536+28
HR_HOPPER_DURATION0
W
This value is written to the corresponding parameter in Section 4.3.
1536+29
HR_SEQUENCE_PARAMETERS_WRITE_TRIG
W
0 or 1
A rising edge trigs the write of the hopper vibration Holding Registers
HR_SEQUENCE_ACTION1_TYPE (Address 1536+31) to
HR_SEQUENCE_ACTION7_DURATION_VALUE (Address 1536+58) to the
sequence parameters (Section 4.4) for the identifier H
HR_SEQUENCE_PARAMETERS_WRITE_ID
1536+30
HR_SEQUENCE_PARAMETERS_WRITE_ID
W
1 to 25
The sequence write trigged with
HR_SEQUENCE_PARAMETERS_WRITE_TRIG uses this Holding Register to
save the values at the given identifier.
Note: The Sequence ID 26 is protected so read-only.
