Chapter 4 – Functions of the instrument
UM-30300D-U User manual AX 6000 Page 40 / 54
3. DATA MANAGEMENT
3.1. RESULTS STORAGE
The device is fitted with an internal memory greater than 1 Go only used for the results
storage, that allows recording several thousands of measurements results. Each
measurements carried out are automatically save at the end of the test.
The results recovery is only carried out from the Winateq300 software; in this
paragraph we will show some frames examples.
3.1.1. Manual mode results frames (Program)
The measurements values and some parameters are stored to be export for later use.
Prog
N°.
Program
name
Test
Current
Max
Reject.
Min
Reject
Measu
re
Unity Results Date Hour
Serial
N°
1 R WING 10 A 1050mΩ 0mΩ 1029 mOhm PASS 23/09/09 09:15:48 01254
2 L WING 1A 1060mΩ 0mΩ 1012 mOhm PASS 23/09/09 09:17:52 01254
3 NOSE 0,1A 1035mΩ 0mΩ 0 mOhm FAIL 23/09/09 09:20:16 01254
3.1.2. Automatic mode frames (Sequence)
In the automatic mode the following fields will be added:
9 Sequence N°.
9 Sequence name (ex: plane reference).
9 Program step in the sequence (from 1 to 999).
9 User identifier.
Seq
N°
Seq
Name
Step
Prog
N°
Name
1
Name
2
Name
3
Test
current
Max
Reject
Min
Reject
Measure
(R)
Unit Result Date Hour User
Serial
N°
Serial
N° 2
1 A320 1 9 WING Left Front 10 A 1050mΩ 0mΩ 1029 mOhm PASS 04/02/13 09:55:38 Jack 01254 0101
1 A320 2 3 WING Right Front 1A 1060mΩ 0mΩ 1012 mOhm FAIL 04/02/13 09:57:52 Jack 01254 0101
1 A320 3 2 NOSE Front mΩ mΩ mOhm TO DO 01254 0101
1 A320 4 5 STAB Right 1A 1050mΩ 0mΩ 952 mOhm PASS 04/02/13 10:03:08 Jack 01254 0101
1 A320 5 5 STAB Rear 1A 1075mΩ 0mΩ mOhm N/A 04/02/13 10:06:17 Jack 01254 0101
