FUNCTIONS OF THE INSTRUMENT
1. MENU STRUCTURE
1.1. MAIN MENU
To access to the main menu, press and hold the ENTER
key until the main
menu appears (about 3 seconds).
MAIN MENU Under menu 1 Under menu 2 Under menu 3
Parameters
> Unlock
V
Lock
V
Erase (password)
V
MODE
> program
V
Sequence
V
PROGRAM
> Pr 01 to Pr 128
V
NAME
V
Current
> 10A
V
1A
V
100mA
V
Maximum reject
(R. MAX.)
> 0 to 6000mΩ
V
Minimum reject
(R. MIN.)
> 0 to 6000mΩ
The maximum thresholds
values can vary following
the chosen range.
V
Measurement ranges
>
Auto > 6Ω > 600mΩ
(200mΩ) > 60mΩ
(20mΩ)> 6mΩ (2mΩ)
The 200mΩ, 20mΩ and
2mΩ ranges are only for the
3A current option.
V
MODE
> Resistive
V
Inductive
V
Automatic
V
Chaining PP
> Off
V
On
This menu appears only in
"sequence" mode
V
System settings
> Language > English
V French
V
Date / Hour > No
