Preamble
UM-30300D-U User manual AX 6000 Page 4 / 54
3. GENERAL DIAGRAM
Voltmeter
Automatic
zero
10 A
1 A
0.1 A
Current
generator
Shunt
Batter
y
Instrumentation
amplifier
I measure
R
X
A B
Probe
Probe
