ATEQ AX6000 User Manual

Chapter 3 – Starting up and adjustments
UM-30300D-U User manual AX 6000 Page 20 / 54
3. MODE FUNCTION
The instrument had two test modes, the Program mode and the Sequence mode.
The Program mode allows running programs individually and unitary. The program to
run choice is made by the user. The programs can be created from the front face of the
device or from the Winateq300 software. 128 different programs can be created.
The Sequence mode allows chaining several programs ones after ones following a
defined order. The sequence choice is made by the user. One program can be in
several different sequences and can be several times into the same sequence. The
sequences can be edited only from a PC fitted with the Winateq300 software.
3.1. PROGRAM NUMBER CHOICE
3.1.1. Main menu mode
In the main menu, put the cursor in front of Program to select
the program to run, validate with the
key.
MAIN
MENU
Parameters: Unlock
Mode : Program
>Program : Pr01
Select the program to run and validate with the key.
PROGRAMS
LIST
PR01
>PR02
PR03
3.1.2. Cycle mode
To select the program to run in the CYCLE mode, use the
and keys, then run the test program with the
key.
Program 1
10A Auto
